UW-NJP-200/400/800 Automatic Capsule Filling Machine

Application:

Pharmaceutical, medicine, and chemicals (powder, Pellet, granule, pill), also can be used to fill vitamin, foodstuff and animal drug, etc.

Features

.Touching-screen, PLC program control panel with LCD.

.Capsule vacuum positioned mechanism to make the capsule qualified over 99%.

. Removable powder hopper for cleaning and easy auger adjustment easy to change fills weights.

. Easy speed selection and closed capsule length adjustment.

. Electrical Appliance control system approved to CE, and international standard.

.Quick and accurate change part set-up, easy to remove rotary table and ring carrier assembly.

.Fully enclosed rotating table and dosage stations for integration of the whole capsule filling plants.

.Large cam mechanism keeps the rotating table of mould together with the whole equipment running in balance, and completely guarantees the machine operating with highest precision and accuracy.



. With high efficiency, accuracy, and energy saving.

. Easier to clean, dismantle and re set-up the mould.

. The working station cam runs under the good lubricating condition, extends the operating life of change parts.

. Improved the inner design of Mould rotating table, Import 90 pcs beeline bearings for each machine from Japan directly, guaranteed the equipment precision and extended the life of machine.

. Easier to clean; keep the dosage in accuracy.

. Enlarge the size of dosage pan (Enlarge 3cm); Increase the powder flowing uniformity in the dosage pan, according to the international standard.

. Adopt three dimensional control elements; Take the undersurface plane of dosage as datum, so as to eliminate the natural transmutation of the dosage pan and copper saucer. It is the special design at domestic (Patent No. 20042006795X).

Technical Details:

Model No.	UW-NJP-200	UW-NJP -400	UW-NJP -800
Capacity	200 capsules/min	400 capsules/min	800 capsules/min
No. of Dose	2	3	6
Suitable for Capsule	00#-4#	00#-4#	00#-4#
Total Power	3kw	3kw	4kw
Overall Weight	700Kg	700Kg	800Kg
Machine Dimension	580 x 900 x 1700mm	730 x 950 x 1700mm	820 x 960 x 1800mm
Accuracy	+ 1% Depending upon the consistency, uniformity & bulk density of powder under the controlled level of humidity.





 Port :   Shanghai or Ningbo

Place of Origin:	Zhejiang in China
Model No:	UW-NJP-200/400/800
Brand Name:	UNIWONDER
Payment Terms:	T/T(Bank Transfer),Western Union,
Minimum Order:	1 Set/Sets
Supply Ability:	500 Set/Sets per Year
Package:	Wooden Case
Delivery Time:	25-30days
